ABB 1SAX201910R0001 DB45EF Overload Relay

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 1SAX201910R0001 DB45EF Overload Relay is an intelligent electronic device for motor protection, providing overload, phase-loss, and short-circuit protection. The DB45EF relay uses electronic detection for precise current monitoring and reliable protection. It can be combined with ABB contactors to provide a complete motor control and protection solution. Its modular design allows easy installation and maintenance, suitable for industrial automation and machinery control applications.

2. Technical Specifications

• Model: 1SAX201910R0001

• Type: Electronic Overload Relay

• Rated Current Range: 0.63–10 A (adjustable)

• Rated Operating Voltage: AC 400 V / DC 24–60 V

• Protection Functions: Overload, phase-loss, short-circuit

• Output Contacts: NO/NC relay contacts

• Response Time: Fast response

• Mounting: Directly combined with contactor or DIN rail mount

• Operating Temperature: 0°C to +60°C

• Storage Temperature: -20°C to +70°C

• Protection Rating: IP20

• Indicators: LED status indicators

• Dimensions (W×H×D): ~45 × 80 × 70 mm

• Weight: ~0.15 kg

3. Advantages and Features

• Accurate current monitoring: Provides real-time motor status for safe operation.

• Multiple protection functions: Overload, phase-loss, and short-circuit protection to prevent motor and equipment damage.

• Adjustable current setting: Flexible adjustment according to motor rated current.

• LED status indicators: Shows relay operating status and fault information for easy maintenance.

• Modular design: Can be directly mounted with contactors, saving space and simplifying maintenance.

4. Typical Applications

• Industrial motor protection and control

• Conveyor systems, pumps, and fan protection

• Motor control in automated production lines

• HVAC systems and compressor protection

• Factory automation and machinery motor protection

5. Installation & Usage Notes

• Ensure relay rated current matches motor before installation.

• Secure all wiring to prevent loose connections or short circuits.

• Install in a dry, ventilated environment to prevent dust or liquid ingress.

• Regularly check LED status and relay operation to ensure system safety.

• Avoid overload operation to prolong relay life.
