ABB 1SAM550000R1009 Manual Motor Starter

1. Product Overview

The ABB 1SAM550000R1009 Manual Motor Starter is designed for direct starting and protection of small three-phase AC motors. It integrates overload and short-circuit protection to prevent motor damage during operation.
With simple operation and compact design, it is widely used in industrial, commercial, and light automation equipment to provide safe and reliable motor start/stop control.

2. Technical Specifications

General

• Model: 1SAM550000R1009

• Type: Manual Motor Starter

• Rated Current: 0.16–0.25 A (adjustable)

• Rated Operating Voltage: AC 240/415 V

• Phases: 3

Protection

• Overload: Thermal-magnetic trip

• Short-circuit: Magnetic trip

• Operation: Manual

• Poles: 3P

• Protection Class: IP20

Mechanical & Environmental

• Control Method: Rotary knob

• Mounting: DIN rail

• Operating Temperature: –25°C to +60°C

• Storage Temperature: –40°C to +70°C

• Mechanical Life: ~10,000 operations

• Material: High-strength flame-retardant plastic

Dimensions & Weight

• Dimensions (L×W×H): ~45×45×70 mm

• Weight: ~0.15 kg

3. Features & Advantages

• Dual protection: overload and short-circuit

• Easy manual operation for motor start/stop

• Compact and space-saving design

• Industrial-grade reliability and long service life

• Adjustable rated current for various motor sizes

• DIN rail mount for easy installation and maintenance

4. Typical Applications

• Light industrial machinery control

• Fans, pumps, electric tools

• Motor control for automated production lines

• Commercial motors and small machinery

• HVAC systems

• Laboratory and educational equipment

5. Precautions

• Disconnect power before installation or removal.

• Set rated current properly to avoid motor overload.

• Install in a dry, ventilated environment free of corrosive gases.

• Do not exceed rated voltage and current.

• Regularly inspect and maintain the mechanical knob and wiring.

• Avoid exposure to high temperatures or direct sunlight.
