ABB 1SAM360000R1009 Manual Motor Starter

• Product Overview

  The ABB 1SAM360000R1009 is a manual motor starter designed for low-voltage motor control and protection. It combines overload, short-circuit, and manual ON/OFF control in a compact device suitable for single-phase or three-phase motors. The unit can be installed directly in control panels or near the motor, making it ideal for industrial and commercial motor drive applications.

  ---

  Main Technical Specifications

  • Model: 1SAM360000R1009

  • Product Type: Manual Motor Starter

  • Rated Current: 6 – 10 A (adjustable)

  • Poles: 3P (three-pole)

  • Operating Voltage: AC 400 V

  • Short-Circuit Breaking Capacity: 10 kA

  • Overload Trip Type: Thermal-magnetic (adjustable)

  • Manual Operation: ON/OFF handle

  • Mounting: DIN rail or screw mount

  • Operating Temperature: ‑25 ℃ to +60 ℃

  • Protection Class: IP20

  • Standards: IEC/EN 60947-2

  ---

  Key Advantages & Features

  1. Comprehensive Motor Protection

     • Integrated overload, short-circuit, and underload protection for enhanced motor safety.

  2. Convenient Manual Operation

     • ON/OFF handle allows easy motor start, stop, and fault switching.

  3. Adjustable Overload Protection

     • Thermal-magnetic overload trip can be adjusted to match motor rated current.

  4. Compact Modular Design

     • Small footprint, easy to install in control panels or near motors.

  5. High Reliability and Industrial Durability

     • Designed for harsh environments; resistant to vibration, high temperatures, and corrosion.

  ---

  Typical Applications

  • Three-phase asynchronous motor control and protection

  • Industrial automation production line motor drives

  • Fans, pumps, and electric motor equipment

  • Engineering machinery and small factory motors

  • HVAC motor protection

  • Branch circuits and local motor protection

  ---

  Installation & Operation Notes

  • Proper Selection: Choose starter according to motor rated current and adjust overload range.

  • Environmental Conditions: Avoid high humidity, dust, and corrosive environments; maintain good ventilation.

  • Wiring Practices: Ensure input and output terminals are securely connected to prevent loose contacts.

  • Operational Safety: Power off before adjusting or maintaining the handle or wiring to avoid electric shock.

  • Routine Maintenance: Check wiring, handle operation, and trip function periodically to ensure reliable long-term performance.

•
•
