ABB 1SAM350000R1014 MS132-25 Manual Motor Starter

• 1. Product Overview

  The ABB MS132-25 Manual Motor Starter is a compact, economical low-voltage motor protection and starting device. It integrates overload protection and short-circuit protection and allows manual operation for safe motor start and stop. The adjustable overload current makes it suitable for direct starting of small three-phase motors, widely used in industrial automation, machinery, and building installations.

  ---

  2. Technical Specifications

  • Model: 1SAM350000R1014 / MS132-25

  • Type: Manual Motor Starter

  • Poles: 3 poles

  • Rated Operational Current (Ie): 25 A

  • Adjustable Overload Current Range: 18–25 A

  • Short-Circuit Protection: Use with appropriate fuses

  • Control: Manual handle operation

  • Rated Insulation Voltage (Ui): 690 V AC

  • Rated Operational Voltage (Ue): AC 400 V

  • Maximum Operating Voltage: AC 500 V

  • Utilization Category: AC-3

  • Mechanical Life: ≥ 20,000 operations

  • Electrical Life: ≥ 6,000 operations

  • Protection Rating: IP20

  • Terminal Type: Screw terminals

  • Operating Temperature: -25°C to +60°C

  • Dimensions (W×D×H): ~75 × 80 × 100 mm

  • Weight: ~0.55 kg

  ---

  3. Advantages and Features

  • Overload and short-circuit protection: Built-in thermal overload protects motor from overheating; fuses provide short-circuit protection.

  • Easy manual operation: Handle allows simple start/stop control on-site.

  • Adjustable overload current: Flexible adjustment to suit motors of different ratings.

  • Compact and reliable: Modular design for easy installation in control panels or distribution boxes.

  • Standards compliant: IEC 60947-2 certified for electrical safety and long-term reliability.

  ---

  4. Typical Applications

  • Industrial automation motor protection and control

  • Start/stop control of small three-phase motors

  • Pumps, fans, compressors, and machinery

  • Distribution systems and low-voltage control panels

  • Production line motor control

  ---

  5. Installation & Usage Notes

  • Ensure the motor rated current matches the starter's adjustable range before installation.

  • Make all connections firm to avoid poor contact, overheating, or misoperation.

  • Regularly check handle, terminals, and overload mechanism condition.

  • Maintain proper ventilation in control panels to avoid high-temperature operation.

  • Disconnect power before maintenance or replacement.

The structure and details of the product： ​
