ABB 1SAJ590000R0102 LCD panel with USB interface

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• 1. Product Overview

  The ABB 1SAJ590000R0102 LCD Panel with USB Interface is a high-performance human-machine interface (HMI) panel for industrial automation. It displays device status, operating parameters, and alarms, and allows data transfer, parameter configuration, and firmware updates via USB. The panel is compatible with ABB drives, PLCs, relays, and other automation devices, providing intuitive operation and monitoring.

  ---

  2. Technical Specifications

  Parameter	Specification
  Model	1SAJ590000R0102
  Type	LCD Panel with USB Interface
  Display Type	LCD (TFT)
  Display Size	4.3-inch color display (approx.)
  Resolution	480 × 272 pixels
  Interface	USB 2.0 (data transfer, parameter configuration), expandable communication ports
  Supply Voltage	24 V DC
  Operating Temperature	-10 ℃ ~ +60 ℃
  Storage Temperature	-20 ℃ ~ +70 ℃
  Protection Rating	IP20 (front panel)
  Mounting	Embedded panel mounting
  Functions	Parameter display, alarm indication, data logging, firmware upgrade
  Status Indicators	LED for power and communication status
  Dimensions	140 × 100 × 35 mm (approx.)
  Weight	~0.25 kg

  ---

  3. Key Features and Benefits

  • Clear TFT color display for operating parameters, alarms, and system information

  • USB interface for data transfer, parameter import/export, and firmware upgrades

  • High compatibility with ABB drives, PLCs, relays, and automation devices

  • User-friendly interface with keys and touch operation for quick access

  • Embedded panel design suitable for industrial control cabinets

  • Built-in LED status indicators for power and communication monitoring

  ---

  4. Typical Applications

  • Operation and monitoring of ABB drives and motor control systems

  • HMI for PLCs and industrial automation systems

  • Parameter display and configuration in industrial control cabinets

  • Process control and production line monitoring

  • Energy, packaging, textile, and machinery equipment HMI

  ---

  5. Installation & Usage Notes

  • Ensure a 24 V DC power supply is used to prevent overvoltage or undervoltage damage

  • Install in environments free from high temperature, humidity, dust, and corrosive gases

  • When using the USB interface, ensure power is on to prevent data loss

  • Securely mount the panel in the cabinet cutout and ensure proper grounding

  • Regularly check display, keys, and interface status to maintain long-term reliable operation

•
