ABB 1SAJ520000R0100 General Purpose Motor Controller

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• 1. Product Overview

  The ABB 1SAJ520000R0100 (UMC100-FBP.0) is a universal motor controller designed for comprehensive protection, control, and monitoring of three-phase induction motors. It integrates motor protection functions, start/stop control, and operating diagnostics, making it suitable for motor control centers, distribution panels, and industrial automation systems.

  ---

  2. Detailed Technical Specifications (Typical Reference)

  Electrical Specifications

  • Adjustable motor current range: 0.24 A – 63 A

  • Rated main voltage: up to 690 V AC

  • Control supply voltage: 24 V DC

  • Digital inputs: 6 × 24 V DC

  • Outputs: 3 relay outputs

  Environmental & Mechanical

  • Operating temperature: 0 to +60 °C

  • Storage temperature: –20 to +70 °C

  • Protection class: IP20

  • Mounting: 35 mm DIN rail

  • Modular design: supports additional I/O and communication modules

  Functional Features

  • Protection: overload, phase loss, unbalance, stall detection, thermal protection

  • Control: motor start/stop, parameter setting, status monitoring

  • Expandability: optional fieldbus modules, I/O expansion modules

  • Diagnostic capability: status indication and fault reporting

  ---

  3. Advantages and Key Features

  • Wide motor current range supporting a variety of motors

  • Integrated protection and control reduces external components

  • High reliability with comprehensive fault and overload protection

  • Modular expansion for flexible system integration

  • Compact DIN-rail mounting for easy installation

  • Suitable for high-voltage motor systems up to 690 V AC

  • Flexible parameter configuration for diverse industrial applications

  ---

  4. Typical Application Areas

  • Industrial automation and production lines

  • Pumps, fans, compressors, and motor-driven equipment

  • HVAC systems (air handling units, chilled water pumps, fans)

  • Motor control and distribution cabinets

  • Machinery manufacturing

  • Centralized motor monitoring and control systems

  • Water treatment, energy, chemical, food, and packaging industries

  ---

  5. Precautions and Recommendations



  • Set motor current parameters according to the motor nameplate.

  • Install inside a fully enclosed control panel to avoid moisture, dust, and corrosive gases.

  • Ensure stable 24 V DC control supply and correct wiring of I/O terminals.

  • Perform periodic checks on terminals, wiring, and relay contacts.

  • Configure communication and expansion modules properly when used.

  • Adjust protection parameters appropriately in high-temperature or high-start-frequency conditions.

•
•

The structure and details of the product：
