ABB 1SAJ510000R0500 General Purpose Motor Controller

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 1SAJ510000R0500 General Purpose Motor Controller is an industrial-grade controller for low-voltage motors, designed for start, stop, forward/reverse, and overload protection. It integrates a contactor, thermal overload relay, and control terminals, supporting direct-on-line (DOL) or star-delta starting. The controller is compact, reliable, and suitable for industrial automation, pumps, fans, compressors, and production equipment motor control.

2. Main Technical Parameters (Typical)

Electrical Data

• Rated operational voltage (Ue): AC 690 V

• Rated operational current (Ie): 5 A

• Control voltage (coil voltage): AC 230 V / DC 24 V (optional)

• Poles: 3 main contacts

• Overload protection: Adjustable thermal relay

Mechanical and Electrical Life

• Electrical life: approx. 150,000 operations

• Mechanical life: ≥ 5,000,000 operations

Control Functions

• Direct-on-line (DOL) or star-delta start

• Forward/reverse control

• Adjustable thermal overload settings

• External control buttons for start/stop/emergency stop

Installation

• DIN rail or panel mounting

• Compact design for control cabinet integration

Operating Environment

• Operating temperature: -25°C to +60°C

• Protection class: IP20

• Suitable for industrial control environments

Standards and Certifications

• Compliant with IEC/EN 60947-4-1, UL 508

• CE certified

3. Advantages and Features

• Integrated design: Contactor, overload protection, and control terminals in one unit

• High reliability: Industrial-grade components ensure safe motor operation

• Versatile control: Supports forward/reverse, DOL, or star-delta starting

• Compact installation: Saves control cabinet space and simplifies maintenance

• Flexible application: Suitable for various low-voltage motors and industrial equipment

4. Typical Applications

• Industrial pumps, fans, and compressors

• Conveyor systems and production line motor control

• HVAC system motor control

• Factory and infrastructure automation

• Water treatment, power, and energy management systems

5. Application Notes

• Ensure motor rated current matches the controller’s rated current

• Select DOL or star-delta start according to control requirements

• Coil voltage must match system power supply

• Ensure proper ventilation to prevent overload

• Periodically check thermal relay settings and terminal tightness

The structure and details of the product：
